FSA-90000 Smoke Alarm Remote Troubleshooting Guide
FSA-90000 SMOKE ALARM REMOTE CONTROLLER TROUBLESHOOTING GUIDE
Troubleshooting guide and other resources for the FSA-90000 smoke alarm remote controller from MATelec Australia
FACTORY RESETTING
Factory Resetting FSA-90000 Smoke Alarm Remote
To restore your FSA-90000 Smoke Alarm Remote to its factory settings, follow the steps.
- 1
Remove Battery
Remove the battery from the back of the remote.
- 2
Press Net Button
Hold the NET button down for 15 seconds then release.
- 3
Reinsert Battery
Reinsert the battery.
- 4
Remote Reset
The remote is now reset.
REMOTE TESTING
How to Test Your Smoke Alarms Using the FSA-90000 Remote
- 1
Press Test
Press the TEST button on the remote.
- 2
LED Flash
The red LED on the remote will flash three times.
- 3
Alarms Sound
After the third flash, all connected alarms will sound for around 25 seconds, confirming the test has been activated.
- 4
Test Complete
Once the test finishes, the red LED on each alarm will flash once every second for three minutes to indicate a successful test.
Using the FSA-90000 Remote with FSA-30000, DET-SMK/RF/AC/1 and /10 Smoke Alarms
Using the MATelec FSA-90000 Remote with FSA-30000, DET-SMK/RF/AC/1 and /10 Smoke Alarms
HUSHING & RESETTING
How to Hush and Identify Triggered Alarms Using the FSA-90000 Remote
- 1
Press Hush
If a false alarm occurs, press the Hush button on the remote. This will silence the triggered alarm for 10 minutes.
- 2
Locate Triggered Alarm
If you have multiple interconnected alarms, you can identify which one triggered by pressing the Locate button on the remote.
- 3
Triggered Alarm Identification
The red LED on the triggered alarm will flash and sound enabling easy identification.
Using the FSA-90000 Remote with FSA-30000, DET-SMK/RF/AC/1 and /10 Smoke Alarms
Using the MATelec FSA-90000 Remote with FSA-30000, DET-SMK/RF/AC/1 and /10 Smoke Alarms
SOS FUNCTION
Using the SOS Function on Your FSA-90000 Remote
The SOS function can be used during non-fire emergencies to quickly alert others in the home.
- 1
Press SOS
Press the SOS button to activate all interconnected alarms.
- 2
Press Locate
To turn off SOS mode, press the Locate button and wait three seconds.
Using the FSA-90000 Remote with FSA-30000, DET-SMK/RF/AC/1 and /10 Smoke Alarms
Using the MATelec FSA-90000 Remote with FSA-30000, DET-SMK/RF/AC/1 and /10 Smoke Alarms
ALARM PAIRING
FSA-90000 Smoke Alarm Remote Pairing Instructions
Follow the below videos to pair the FSA-90000 Smoke Alarm Remote with a MATelec Australia RF-enabled smoke alarm.
Pairing FSA-90000 Remote with DET-SMK/RF/AC/1 and /10
Pairing the MATelec FSA-90000 Wireless Remote with MATelec DET-SMK/RF/AC/1 and /10 Smoke Alarms
Pairing FSA-90000 Remote with FSA-30000 and FSA-60000
Pairing the MATelec FSA-90000 Wireless Remote with MATelec FSA-30000 and FSA-60000 (with FSA-50000 Wireless Module) Smoke Alarms
Pairing FSA-90000 Remote as Master Controller
Pairing the MATelec FSA-90000 Remote as the Master Controller in a network of MATelec Smoke Alarms, rather than the smoke alarm itself. This means that it is a bit easier to add more alarms to the network in future.
