FPC-12XX-XX-SE
Sewage & Wastewater Hydrostatic Level Transducers
IP68-rated, pipe-mounted level transducer with 4-20mA output in 316 SS housing, for sewage and wastewater applications.
Overview
Sewage and Wastewater Hydrostatic Level Transducers are designed to be mounted to a pipe and provide precise level readings using a 4-20mA signal. Featuring excellent anti-interference characteristics in a robust 316 stainless steel housing and suitable for temperatures from -10°C to 70°C.
- Excellent repeatability and long-term stability
- Excellent anti-interference ability
- Measure depth or level measurement in potable, raw, ground and rainwater, sewage and wastewater applications.
Product Details
SPECIFICATIONS
- Overload Pressure: 1.5 times full scale
- Accuracy: ± 0.5% F.S
- Supply Voltage: 12-30Vdc, 24 Vdc
- Output Signals: 4-20mA
- Response Time: 10ms
- Temperature Ranges:
- Compensated: 0°C - 50°C
- Media: -10°C - 70°C
- Environment: -30°C - 85°C
- Storage: -40°C - 125°C
- Temperature Compensation: 0.02% F.S./°C
- Electrical Connection: 3 Wires, Breather Tube
- Protection Classification: Sensor is IP68
- Vibration: 20g ; 20-5000Hz
- Housing Material: 316 Stainless Steel
- Operating Life: >1x108 Pressure Cycles
- Cable Details:
- Diameter: Ø7.5mm OD
- Material: PUR Polyurethane
SKU Details
Sewage Transducer Range
| SKU | Description | Depth Range | Cable Length |
| FPC-12569-10-SE | Hydrostatic Level Transducer - Sewage | 0 - 1m | 10m |
| FPC-12570-24-SE | Hydrostatic Level Transducer - Sewage | 0 - 10m | 24m |
| FPC-12570-10-SE | Hydrostatic Level Transducer - Sewage | 0 - 10m | 10m |
| FPC-12570-30-SE | Hydrostatic Level Transducer - Sewage | 0 - 10m | 30m |
| FPC-12572-10-SE | Hydrostatic Level Transducer - Sewage | 0 - 2.5m | 10m |
| FPC-12575-10-SE | Hydrostatic Level Transducer - Sewage | 0 - 4m | 10m |
| FPC-12575-30-SE | Hydrostatic Level Transducer - Sewage | 0 - 4m | 30m |
| FPC-12575-50-SE | Hydrostatic Level Transducer - Sewage | 0 - 4m | 50m |
| FPC-12575-24-SE | Hydrostatic Level Transducer - Sewage | 0 - 4m | 24m |
